| Description | 7 Tyne | 9 Tyne | 11Tyne |
| No. of Tynes | 7 | 9 | 11 |
| Mounting CAT | CAT-II | CAT-II | CAT-II |
| MAIN FRAME | 100X50 mm Channel | 100X50 mm Channel | 100X50 mm Channel |
| 65x65x6 mm support for Tyne | 65x65x6 mm support for Tyne | 65x65x6 mm support for Tyne |
| SIZE OF TYNE | 25mm Thickness (FORGED EN8) | 25mm Thickness (FORGED EN8) | 25mm Thickness (FORGED EN8) |
| NO. OF SPRINGS | 14 | 18 | 22 |
| SHOVEL | 8 mm(EN-42) | 8 mm(EN-42) | 8 mm(EN-42) |
| WORKING WIDTH RANGE | 1640 | 2050 | 2570 |
| OVERALL LENGTH/WIDTH/HEIGHT | 900/1610/965 | 900/2020/965 | 900/2475/965 |
| SPACING BETWEEN TYNES | 230 | 230 | 230 |
| WEIGHT (approx)Kg | 225 | 280 | 340 |
| SUITABLE HP RANGE | 35-45 | 35-50 | 55-70 |
