Description
SPECIFICATION
| DESCRIPTION | JCTH-20 | JCTH-24 |
| GANG AXLE/BOLT(mm) | 28(SOLID SQ. ROD) | |
| NO. OF DISC | 20 | 24 |
| TYPE OF DISC | PLAIN/NOTCHED DISC (OPTIONAL) | |
| DISC DIAMETER(mm) | 508X3 T OR 558X4 T | |
| TILLAGE WIDTH(mm) | 2410 | 2840 |
| OVERALL WIDTH(mm) | 2255 | 2710 |
| DISTANCE BETWEEN DISCS(mm) | 230 | |
| NO. OF BEARING HUBS | 8(UC211) | |
| WEIGHT(KG) APPROX. | 580 | 640 |
| TRACTOR(HP) | 55-65 | 75-90 |
