| Code | Body Dia ØA (mm) | Usable Length B (mm) | Pin Dia ØC (mm) | Thread Dia ØD (mm) | Weight (lbs.) |
|---|---|---|---|---|---|
| JCS-01 | 6.35 | 25.87 | 7.93 | 5/16″ UNC | 0.14 |
| JCS-02 | 7.93 | 31.75 | 9.52 | 3/8″ UNC | 0.22 |
| JCS-03 | 9.52 | 36.51 | 11.11 | 7/16″ UNC | 0.31 |
| JCS-04 | 11.11 | 42.85 | 12.7 | 1/2″ UNC | 0.53 |
| JCS-05 | 12.7 | 49.21 | 15.87 | 5/8″ UNC | 0.75 |
| JCS-06 | 15.87 | 63.5 | 19.05 | 3/4″ UNC | 1.1 |
| JCS-07 | 19.05 | 76.2 | 22.22 | 7/8″ UNC | 2.75 |
| JCS-08 | 22.22 | 82.55 | 25.4 | 1″ UNC | 3.58 |
| JCS-09 | 25.4 | 95 | 28.57 | 1-1/8″ UNC | 5.4 |
| JCS-10 | 28.57 | 107.95 | 31.75 | 1-1/4″ UNC | 7 |
| JCS-11 | 13.75 | 114.3 | 34.92 | 1-3/8″ UNC | 9.5 |
