| Code | Dim. A | Dim. B | Dim. C | Dim. D | Thread E |
|---|---|---|---|---|---|
| JDHA01 | 7/8″ | 22″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA02 | 7/8″ | 22-1/2″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA03 | 7/8″ | 25-1/4″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA04 | 7/8″ | 26″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA05 | 7/8″ | 30-1/2″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA06 | 7/8″ | 33″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA07 | 7/8″ | 39-1/8″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA08 | 7/8″ | 40-1/4″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA09 | 7/8″ | 41-3/4″ | 1/2″ | 1-3/8″ | 7/8 UNC |
| JDHA10 | 1″ | 19″ | 1/2″ | 1-1/2″ | 1″ UNC |
| JDHA11 | 1″ | 26-1/2″ | 1/2″ | 1-1/2″ | 1″ UNC |
| JDHA12 | 1″ | 34″ | 1/2″ | 1-1/2″ | 1″ UNC |
| JDHA13 | 1-1/8″ | 12″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA14 | 1-1/8″ | 26-1/4″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA15 | 1-1/8″ | 22″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA16 | 1-1/8″ | 31″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA17 | 1-1/8″ | 31-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA18 | 1-1/8″ | 34″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA19 | 1-1/8″ | 40″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA20 | 1-1/8″ | 40-1/4″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA21 | 1-1/8″ | 42″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA22 | 1-1/8″ | 49-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA23 | 1-1/8″ | 56-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA24 | 1-1/8″ | 58-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA25 | 1-1/8″ | 64″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA26 | 1-1/8″ | 67-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA27 | 1-1/8″ | 71-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA28 | 1-1/8″ | 76-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA29 | 1-1/8″ | 79″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA30 | 1-1/8″ | 85-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA31 | 1-1/8″ | 94-1/2″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA32 | 1-1/8″ | 95-11/16″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
| JDHA33 | 1-1/8″ | 104-11/16″ | 1/2″ | 1-5/8″ | 1-1/8 UNC |
